What an incredible journey it has been! This week is the presentations week for the BHE3233 and BTS4433 cohorts. After weeks of development through our tiered scaffolding approach—moving from Stage 1 (Workout Programming) to Stage 4 (Comparative Optimization)—every student successfully presented their hardware architectures.

Watching everyone dissect, design, and compare four distinct digital systems was a proud moment for the UMPSA STEM Lab. But how exactly do these projects tie into our overall syllabus, and how have they built the critical Verilog coding criteria our students will take into the industry?

Let’s break it down.

The Projects: Four Pillars of Digital System Design
The course syllabus was intentionally structured to expose students to four highly distinct industry domains. By encouragung students to design and then optimize each of these systems, the syllabus ensured a comprehensive grasp of real-world hardware challenges:

1. Project 1: Cryptography (Security-Focused): Students dove into hardware encryption by designing an 8-bit AES S-Box. By Stage 4, they compared a memory-heavy Look-Up Table (LUT) approach against an area-efficient Logic-based (Boolean/Galois Field) approach, learning how to select architectures based on whether they are building a high-speed processor or a low-area IoT device.
2. Project 2: CPU / ALU Design (Arithmetic-Focused): Escalating a basic multiplier to 16-bit logic, students had to evaluate complex mathematical trees. They compared Behavioral, Sequential (Shift-and-Add), and Pipelined multipliers. This taught them the delicate balance between saving Logic Elements (LEs) for handheld devices versus maximizing throughput for heavy computation.
3. Project 3: DSP & Sensor Processing: Students built a 4-tap FIR filter, calculating precise bit-widths to prevent arithmetic overflow. The final optimization challenged them to shift from a Direct Form to a Transposed Form architecture, proving that mathematically identical Verilog code can yield vastly different Max Frequencies (fMAX) simply by shortening the critical path.
4. Project 4: Communication Protocols (Interfacing): Focusing on high-reliability data transmission, students built a UART Controller with an integrated Baud Rate Generator and Parity checking. By comparing Binary-Encoded FSMs against One-Hot Encoded FSMs, they learned how Verilog state machine encoding directly impacts flip-flop utilization and setup slack.

Building Verilog Criteria: Beyond Syntax
The most valuable outcome of this class is how it transformed the students’ Verilog coding criteria. The tiered scaffolding intentionally guided them through a specific evolutionary process:

1. Code Comprehension & Hardware Inference (Stage 1): Students learned that Verilog isn’t just software code; it is a description of physical hardware. They learned how a simple * operator is interpreted by the Quartus synthesis engine.
2. Debugging Hardware Logic (Stage 2): They learned to identify hardware-specific malfunctions, such as standard compliance errors (“Output port has no driver”) and catastrophic “Race Conditions” caused by using blocking assignments (=) instead of non-blocking assignments (<=) in sequential logic.
3. Architectural Integration (Stage 3): They learned how to connect verified sub-modules into complex top-level architectures, carefully calculating bit-growth across the data path.
4. Scientific Optimization (Stage 4): This is where they built their highest-level Verilog criteria. They learned to rely on the Quartus TimeQuest Timing Analyzer and Resource Utilization reports to justify their designs, comparing Total Logic Elements, Registers, Max Frequency (fMAX), and Latency.

Preparing for the Engineering Tasks
As noted in the course materials, escalating designs to handle complex optimizations moves a student from simply “making things work” to “optimizing things for performance,” which is the hallmark of a true Digital Design Engineer.

Congratulations to all the BHE3233 and BTS4433 students! You didn’t just write Verilog this semester; you intelligently traded Area for Speed, evaluated critical paths, and solved complex timing puzzles. You are now fully equipped to tackle modern FPGA and ASIC design challenges in the industry!

1. 1. Table-Based (ROM/LUT) Approach: This method acts like a cheat sheet, pre-calculating every possible answer and storing it in memory
      1. While extremely fast (constant time), it consumes significant memory resources and scales poorly. It is highly suited for high-speed cryptographic processor.
   2. Logic-Based (Boolean) Approach: This method acts like a math formula, calculating Galois Field arithmetic in real-time using layers of logic gates
      1. It uses very little memory and is highly area-efficient, making it the perfect choice for low-area IoT devices, though it suffers from a longer propagation delay due to the deep logic tree.

1. 1. Sequential (Shift-and-Add) Multiplier: By mimicking manual long multiplication, this architecture reuses a single adder over multiple clock cycles
      1. It dramatically saves on Logic Elements (LEs), but the cost is high latency, making it ideal for space-constrained, battery-powered handheld devices
   2. Pipelined Multiplier: To maximize performance, students inserted registers into the combinational logic “fences” to break up the deep mathematical tree
      1. Like an assembly line, this allows a new multiplication operation to begin every single clock cycle.
      2. It costs far more registers, but drastically increases throughput and fMAX​, which is mandatory for applications executing millions of operations per second.

Project 3: DSP and Sensors (Direct vs. Transposed FIR Filters)

1. 1. Direct Form: The standard approach where all multiplications happen in parallel, and the results are summed up in a large “Adder Tree”. Its major flaw is a massive Critical Path—the signal must traverse a multiplier and the entire chain of adders before the clock cycle ends, severely limiting the maximum frequency.
   2. Transposed Form: By strategically placing delay registers between the adders, students shortened the critical path so the signal only propagates through one multiplier and one adder per cycle. While this slightly increases Total Registers (FFs), it yields a substantially higher fMAX​ (often a 25% improvement), making it the superior architecture for high-speed 100MHz digital audio processors

1. 1. Binary Encoding: This style uses the absolute minimum number of Flip-Flops (e.g., 2 FFs for 4 states). While it saves physical area on the silicon, it requires heavier combinational logic to decode the states
   2. One-Hot Encoding: This style assigns exactly one Flip-Flop per state (e.g., 4 FFs for 4 states)
      1. Despite consuming more physical area, the decoding logic becomes incredibly simple. This translates to better Setup Slack and a much faster fMAX​, proving that sometimes using more hardware actually makes your system perform better

I look forward to your creativity in executing these projects. Please complete your submissions in KALAM =)

Hi everyone,

After successfully navigating code comprehension and hardware debugging in Stages 1 and 2, our journey through digital system design enters its most advanced phases. This week, we focused on Stage 3: Semi-Completed Programming and Stage 4: New Programming Task (Comparative Optimization).

These stages push us beyond merely “making it work” to actually architecting complete systems and evaluating trade-offs like true digital design engineers. Here is a breakdown of our milestones and the core learning outcomes for each project.

Stage 3: Semi-Completed Programming (Architectural Completion)

In Stage 3, we took foundational components and integrated them into complete, functioning architectures.

Project 1: AES Cryptography (The Logic-Optimized S-Box)

• • The Challenge: Transitioning away from a memory-heavy Look-Up Table (LUT) to a logic-optimized approach using Galois Field (GF(2)) composite arithmetic. We had to complete the missing Boolean equations for multiplicative inversion.


• • Learning Outcome: Mastering Mathematical Hardware. We learned how complex cryptography math (like Galois Fields) is synthesized into pure Boolean logic (XOR, AND, OR gates), demonstrating how a “calculation” approach saves memory at the cost of logic depth.


Project 2: The Multiplier (Pipelining for Speed)

• • The Challenge: We upgraded a combinational multiplier by inserting registers into the middle of the logic “fences” to create a Pipelined Multiplier.

  • Learning Outcome: Increasing Throughput. By breaking a long combinational path into smaller stages, we learned how pipelining allows a new multiplication to start every clock cycle, drastically increasing the system’s Max Frequency (fmax)

Project 3: FIR Filter (Structural Integration)

• • The Challenge: We integrated our verified Multiply-Accumulate (MAC) units and Delay Lines to build a complete Direct Form FIR Filter.
  • Learning Outcome: Preventing Arithmetic Overflow. The crucial lesson here was calculating exact bit-widths for signal growth. We learned that multiplying two 4-bit inputs yields an 8-bit output, and accumulating three of these 8-bit partial products requires a 10-bit final output to prevent overflow.

Project 4: UART Controller (The Transmitter FSM)

• • The Challenge: Wrapping raw serial data into a standardized UART frame by building a Finite State Machine (FSM) that transitions through IDLE, START, DATA, and STOP states based on precise “ticks” from our Baud Rate Generator.

  • Learning Outcome: Protocol Synchronization. We learned how to reliably sequence hardware operations using FSMs, ensuring that communication lines are held HIGH during idle and strictly synchronized to a predetermined baud rate for data integrity.

Moving on

Stage 4: Comparative Optimization (New Programming Tasks)

Stage 4 is where engineering design trade-offs shine. We escalated our designs and used Quartus tools (like the Timing Analyzer and Resource utilization reports) to scientifically compare competing architectures.

Project 1: AES Cryptography (LUT vs. Logic Trade-offs)

• • The Challenge: We integrated both the Stage 1 (Table-based) and Stage 3 (Logic-based) architectures onto the DE10-Lite FPGA, using a hardware switch to “toggle” between them.

  • Learning Outcome: Resource vs. Speed Optimization. By running a Static Timing Analysis (STA), we learned to scientifically deduce which architecture to use depending on the application—evaluating why a LUT is better for a high-speed cryptographic processor while Boolean logic is superior for a low-area IoT device.


Project 2: The Multiplier (16-bit Escalation)

• • The Challenge: We escalated our multiplier from 4-bit to 16-bit and compared all three architectures: Behavioral, Sequential, and Pipelined.

  • Learning Outcome: Evaluating Complex Architectural Trade-offs. We learned how expanding bit-widths exponentially deepens the logic tree. The outcome was understanding how to choose an architecture based on strict constraints (e.g., choosing sequential for space-constrained handhelds vs. pipelined for high-performance CPU ALUs).


Project 3: FIR Filter (Direct vs. Transposed Form)

• • The Challenge: We redesigned our filter into the Transposed Form, a mathematically identical structure that places delay registers between the adders rather than at the input.

  • Learning Outcome: Shortening the Critical Path. We learned a major DSP optimization technique: by separating combinational adders with registers, we shortened the critical path delay. Even though this uses slightly more Logic Elements, it dramatically boosts the f max making it ideal for high-speed audio/sensor processing.

Project 4: UART Controller (FSM Encoding & Parity)

• • The Challenge: We expanded the UART to 16-bit with Even Parity error checking and compared two FSM architectures: Binary Encoding versus One-Hot Encoding.

  • Learning Outcome: FSM Encoding Trade-offs. We gained hands-on experience in how the Quartus compiler assigns flip-flops. We discovered that Binary Encoding saves area (fewer flip-flops) but requires heavier decoding logic, whereas One-Hot Encoding uses more flip-flops but simplifies decoding, resulting in better setup slack and a faster maximum frequency.
